Input Type:Digital
Output Type:Analog
Signal Acquisition Range:-5 to +5 VDC
Isolation Rating:1000V AC
Environmental Operating Temperature:-40°C to +70°C
Power Consumption:Max 5W
Operating Voltage:24V DC
Dimensions (L x W x H):100mm x 50mm x 20mm
Weight:0.15kg
The WOODWARD 5463-581 Isolated Input Module is engineered for unparalleled performance in demanding industrial environments. Its robust design ensures stable operation across a wide temperature range, making it suitable for various applications from manufacturing floors to remote installations.
Featuring an isolation rating of 1000VAC/1500VDC, this module significantly enhances system safety by preventing electrical interference and ensuring data integrity, crucial for critical control systems.
With an operating voltage range from DC 12 to 48V, the module is compatible with a broad spectrum of power sources, providing flexibility in integration with diverse industrial setups.
The module’s input resistance of 1 KΩ is carefully selected to minimize load effects on the source circuit, ensuring accurate signal measurement without causing significant current draw.
Equipped with a current capacity of 5mA, the WOODWARD 5463-581 Isolated Input Module can handle small to moderate current signals, making it versatile for a wide range of sensor inputs in automation and control systems.
