Connection Technology – Communication/Fieldbus:PROFIBUS: 1 x D-Sub 9 socket
Connection Technology – Field Supply:6 x CAGE CLAMP®
Connection Technology – System Supply:2 x CAGE CLAMP®
Connection Technology – Device Configuration:1 x 4-pole male connector
Solid Conductor:Solid conductor
Fine-Stranded Conductor:0.08 … 2.5 mm² / 28 … 14 AWG
Strip Length:8 … 9 mm / 0.31 … 0.35 Inch
System Supply Voltage:DC 5 V; via data contacts
Field Supply Voltage:DC 24 V (-25 … 30 %); via wiring level (CAGE CLAMP® connection)
Width:12 mm / 0.472 inch
Height:69.8 mm / 2.748 inch
Depth:100 mm / 3.937 inch
Weight:32.298 g
Material:Polycarbonate, polyamide 6.6
Color:Light Gray
Operating Temperature Range:-40 … 85 °C
Storage Temperature Range:-40 … 85 °C
Relative Air Humidity:95 % (no condensation)
Mounting Type:DIN-35 rail
The Wago 750-333 Digital & Analog Signals Module is meticulously engineered to deliver high-performance digital and analog signal processing capabilities within your industrial automation setup.
This module is designed to withstand harsh environmental conditions, ensuring consistent operation across various industrial applications.
Its compact size and robust build make it ideal for space-constrained environments, while its easy installation process on standard DIN rails simplifies integration into existing systems.
With its advanced connection technologies, including CAGE CLAMP® terminals for secure connections and a D-Sub 9 socket for reliable communication, this module offers unparalleled reliability and flexibility in signal management.
Whether you’re working in manufacturing, energy, or any other industrial sector, the Wago 750-333 ensures seamless integration and enhanced operational efficiency.
