NI PXIE-2514 High-Performance Data Acquisition Module

In stock

The NI PXIE-2514 is an advanced FPGA module designed for high-performance digital signal processing applications. It integrates state-of-the-art field-programmable gate array technology, enabling flexible configuration for various industrial control systems and testing environments.

Order Number:PXIE-2514

Brand:National Instruments

Series:PXIe

Module Type:Data Acquisition

Input Channels:32 Single-Ended or 16 Differential

Sampling Rate:Up to 2 MS/s per channel

Resolution:16-bit

Analog Input Range:+/-10V

Interface:PCI Express x1

Dimensions:4-slot PXI/PXIe Module

Operating Temperature:-40°C to +85°C

Certifications:CE, RoHS compliant

The National Instruments PXIE-2514 Data Acquisition Module offers unparalleled performance and precision for a variety of industrial applications. Designed with advanced technology, this module supports high-speed data acquisition with a sampling rate of up to 1 MS/s, making it perfect for real-time monitoring and control systems.

Key Design Highlights:

– High-resolution 16-bit ADC for accurate measurements

– Robust construction suitable for harsh industrial environments

– Broad operating temperature range ensures reliable operation

– Compact size allows for easy integration into existing systems

Usage Instructions:

The PXIE-2514 can be easily integrated into your existing PXI Express chassis. Connect it via standard PXIe connectors to the data bus and configure settings through NI software interfaces for optimal performance. Regular maintenance and calibration are recommended to maintain accuracy over time.

NI PXIE-2514
