HYBRICON 078-453 Digital Input Module

In stock

The HYBRICON 078-453 Analog Input Module is designed for efficient and reliable data acquisition in industrial automation systems. It provides precise measurement capabilities for various applications including process control, manufacturing, and monitoring systems.

Manufacturer:Hybricon

Model:078-453

Module Type:Digital Input Module

Input Channels:16

Voltage Range:12-48V DC

Power Consumption:2W

Operating Temperature:-25°C to +70°C

Storage Temperature:-40°C to +85°C

Humidity Range:5% to 95% non-condensing

Communication Protocol:Modbus RTU

Dimensions:120mm x 80mm x 40mm

Weight:0.3kg

This communication module is built with the latest technology to ensure seamless integration with existing systems. Its full software configuration capability eliminates the need for manual module jumpers, enhancing ease of use. With six hardware analog-to-digital filter frequencies, each channel can independently select its own filtering frequency, ensuring rapid data acquisition and automatic calibration. The module supports multiple input types, including RTD short circuit detection, user-defined range scaling, and high/low alarm detection, with detailed fault reporting and diagnostic capabilities. The HYBRICON 078-453 is designed for universal application, capable of replacing third-party modules like thermocouples, strain gauges, RTDs, voltage, and current modules. It offers superior performance with its built-in 10M/100M switchable Ethernet ports, fully compliant with TCP/IP standards for easy network integration. The Genius network’s unique high immunity to interference allows for long-distance communication using shielded twisted pair cables up to 2.3 km, or fiber optics up to 15 km, without the need for repeaters or active terminators. This ensures reliable and stable operation even in harsh industrial environments.
