Type:Solid-State Pressure Sensor
Manufacturer:Allen-Bradley
Model:836P-D2NFGB50PA-D4
Pressure Range:0-100 psi
Operating Voltage:10-30 VDC
Output Signal:4-20 mA
Accuracy:+/- 0.5% Full Scale
Response Time:< 100 ms
Temperature Range:-20°C to +85°C
Electrical Connections:M12 Connector
Material:Stainless Steel
The A-B 836P-D2NFGB50PA-D4 Solid-State Pressure Sensor offers reliable performance in harsh environments. Its robust design includes a NEMA 4X/IP67 protection rating, making it suitable for outdoor and washdown applications. This sensor features an accuracy of +-0.25% full scale, ensuring precise measurements under varying conditions. With a wide operating temperature range from -40°C to +85°C, this sensor can withstand extreme temperatures without compromising its accuracy. The fast response time of less than 20 milliseconds ensures quick detection and immediate action. The sensor is compatible with 10-30 VDC power supplies and outputs a 4-20 mA signal, making it easy to integrate into existing systems. Installation is straightforward thanks to the 1/4″ NPT female electrical connection.
