Allen-Bradley 1756-CN2RXT ControlNet Redundant Bridge Module

Model Type:Bridge Module

Model Number:1756-CN2RXT

Manufacturer(s):Allen-Bradley

Communication Protocol:ControlNet

Number of Channels:2

Amperage Rating:Drawn: 970 mA at 5.1 VDC, 1.7 mA at 24 VDC

Isolation:30 V (Continuous), Basic Insulation Type

Basic Insulation Testing:Type tested at 500 VAC for 60 sec

Enclosure:Open Type

RfI Suppression:Radiated: 10 V/M with 1 KHz sine-wave 80% AM from 80 – 2000 MHz

Conducted:10 VRMS with 1 KHz sine-wave 80% AM from 150 kHz – 80 MHz

Temperature Range:-40°C to +85°C

    The AB 1756-CN2RXT ControlNet Redundant Bridge Module is a cornerstone in modern industrial automation systems, designed to enhance system reliability through redundant network connections. This module ensures that critical data is transmitted efficiently and reliably between two ControlNet networks, providing a fail-safe mechanism against single-point failures.

    Crafted with precision by Allen-Bradley, this module boasts an impressive current rating, allowing it to handle demanding industrial applications without compromising on performance. The open type enclosure ensures durability and ease of installation, while the high-end isolation technology safeguards against electrical interference, ensuring uninterrupted operation in even the most challenging environments.

    With its comprehensive RFI suppression capabilities, the AB 1756-CN2RXT is equipped to handle a wide range of electromagnetic disturbances, maintaining data integrity across its operational spectrum. Its temperature resistance allows for deployment in a variety of industrial settings, from freezing cold to scorching heat.

    Designed with user-friendliness in mind, the module features intuitive connectivity options that facilitate easy integration into existing ControlNet networks. This makes it an ideal choice for upgrading legacy systems or integrating new technologies into established automation setups.

    At the heart of the AB 1756-CN2RXT lies its commitment to safety and reliability. By providing redundancy, it ensures continuous operation even under unexpected conditions, safeguarding critical processes and reducing downtime. Whether you’re looking to enhance your existing infrastructure or build a new automation system from scratch, the AB 1756-CN2RXT ControlNet Redundant Bridge Module is the perfect solution to elevate your industrial automation capabilities.
